Tooling to meet your needs.

We at Stone Mountain Tool, take the challenges that the ever-changing world of electronics manufacturing throws at us head-on. We excel in the more exotic and complex applications that others tend to shy away from. We are not here to simply build you any old fixture, but rather to solve the problems at hand and to provide a practical, applicable solution.

Stone Mountain Tool pallets are not only designed, but are engineered to withstand the daily manufacturing environment. We use all-lightweight yet durable materials on all of our pallets and machine them with as much weight reduction as possible.

Our fixtures are custom designed to fit your needs, whether it’s a simple window frame to support a PCB through the wave, or a highly complex double-sided board with close SMD’s to thru-holes that will require Titanium inserts to provide durable sealing walls to prevent flooding. Whatever your needs may be, we are equipped to handle them and to provide you with a quality product.

With a design staff unmatched in the industry, we will provide you with the best tooling available that is reliable, easy to use, and able to withstand the rigors of the manufacturing environment. Incorporated into every pallet design are operator friendly, advanced engineered hold down components. Ergonomically enhanced assemblies are constructed from durable, lightweight materials. A simple design and emphasis on ease of use improves the interface between man and machine.

Creative Solutions
Our team of experienced designers apply 35 years of knowledge when developing a solution to your specific application. We focus on providing a cost-effective, reliable & robust tooling solutions.
Capability
The design review package we provide includes 2D detailed prints and 3D static model. To aide in ensuring compliance, we also provide a virtual model that allows you to manipulate the model’s position for all-angle inspection.
Materials
We manufacture our pallets and tools from the most advanced and proven epoxy or polyester composites. We incorporate the benefits of other materials in our design to effectively address harsh manufacturing environments.
